AU8910

Layout
  AU8910 1152 Xor 6771_256
Mix
  Input
    Order  0
  Block Pair
    Block  0xc00000
    Page   0x4000
Assembler
  Block Number
    Block Size   0x1800000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x2e3
  Actions
    Scan
Comments
  Serg for forum 12142

AU89102DF   2c a4 08 32   1x1   KP9flash extractor   Layout AU6989 1152 Xor 6771_256 Mix Input Order 0 Block Pair Block 0x2400000 Page 0x4000 Assembler Virtual Translator Block Size 0x4800000 Comments by Arvika Run auto slow, than auto fast Or rebuild VT manually

KP9flash extractor

Layout
  AU8910 1152 Xor 6771_1728_256
Mix
  Input
    Order  1/0
  Block Pair
    Block  0x5100000
    Page   0x4000
  Join by Dump
    Parts  2
Assembler
  Virtual Translator
    Block Size  0xa200000
Comments
  by Arvika
  MBR need rebuild manually

KP9flash extractor

Layout
  AU8910 1150 Xor 6771_1728_256
Mix
  Input
    Order  1/0
  Software Bad Bytes
    Block  5184
    Group  1
  Block Pair
    Block  0x5100000
    Page   0x4000
  Cross Bank
    Block  0xa200000
    Bank   0xe7
  Join by Dump
    Parts  2
Assembler
  Block Number
    Block Size   0xa200000
    Bank Space   0xe7
    Image Cut    0x40000
  Actions
    Scan
    Find Bank Size
Comments
  Serg for forum 11979

KP9flash extractor

Layout
  AU8910 1152 Xor 6771_1728_256
Mix
  Input
    Order  1/0
  Block Pair
    Block  0x5100000
    Page   0x4000
  Cross Bank
    Block  0xa200000
    Bank   0xe7
  Join by Dump
    Parts  2
Assembler
  Block Number
    Block Size   0xa200000
    Bank Space   0xe7
  Actions
    Scan
    Find Bank Size
Comments
  Serg for forum 12270

AU89102DF   45 3c 98 b3   1x4   KP9flash extractor   Layout AU8910 1136 Xor 6771_256 Mix Input Order 0/1/2/3 Software Bad Bytes Block 768 Group 2 Block Pair Block 0xc00000 Page 0x4000 Join by Page Parts 2 Page 0x8000 Cross Bank Block 0x3000000 Bank 0x200 Join by Dump Parts 2 Assembler Block Number Block Size 0x3000000 Bank Space 0x800 Banks 00 / 0x000 / 0x4c2 01 / 0x000 / 0x4e5 Actions Scan Comments by Arvika SBB: Auto ff

KP9flash extractor

Layout
  AU8910 1152 Xor 6771_1728_256
Mix
  Input
    Order  0
  Block Pair
    Block  0x5100000
    Page   0x4000
  Cross Bank
    Block  0xa200000
    Bank   0xe7
Assembler
  Block Number
    Block Size   0xa200000
    Bank Space   0xe7
  Actions
    Scan
Comments
  Serg for forum 11984

  Tested with Raw Recovery
  I do not make Check Dirs

KP9flash extractor

Layout
  AU8910 1162 Xor 6771_0x6c0_256
Mix
  Input
    Order  1/0
  Block Pair
    Block  0x5100000
    Page   0x4000
  Block Pair
    Block  0xa200000
    Page   0x8000
  Join by Page
    Parts  2
    Page   0x10000
Assembler
  Raw
Comments
  Serg for forum 12851

  Can not build VT
  Each top dir have alot of updates

KP9flash extractor

Layout
  AU8910 1162 Xor 6771_256
Mix
  Input
    Order  1/0
  Block Pair
    Block  0x2400000
    Page   0x4000
  Block Pair
    Block  0x4800000
    Page   0x8000
  Join by Dump
    Parts  2
Assembler
  Block Number
    Block Size   0x9000000
    Bank Space   0x4000
    Image Cut    0x8000
    Banks        00 / 0x000 / 0x3bc
  Actions
    Scan
Comments
  by Arvika
  dump order can be other
  structure was borken, need rebuild.

KP9flash extractor

Layout
  AU8910 1146 Xor 6771_384_256
Mix
  Input
    Order  0
  Block Pair
    Block  0x1800000
    Page   0x4000
  Block Cut
    Block  0x2400000/0xC00000
Assembler
  Block Number
    Block Size   0x2400000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x3ff
  Actions
    Scan
Comments
  Serg for forum 12806
