AU6984

2024-02-23 14:03:11

AU6984 ad d3 14 a5 1x2

司法鉴定，质量鉴定, 电子数据，声像资料

f0jflash extractor

Layout

AU6984 528

Mix

Input

Order 0/1

Block Pair

Block 0x40000

Page 0x800

Join by Page

Parts 2

Page 0x1000

Assembler

Block Number

Block Size 0x100000

Bank Space 0x400

Actions

Scan

Find Bank Size

Comments

by Arvika

check conflicts

AU6984 ad d5 14 b6 2x1

Layout

AU6984 528

Mix

Input

Order 1/0

Join by Byte

Parts 2

Data false

Assembler

Block Number

Block Size 0x100000

Bank Space 0x400

Actions

Scan

Find Bank Size

Comments

by Vlad forum 5252

many many blocks were erased

AU6984 ec d3 14 a5 1x1

司法鉴定，质量鉴定, 电子数据，声像资料

f0jflash extractor

Layout

AU6984 528

Mix

Input

Order 0

Block Pair

Block 0x40000

Page 0x800

Assembler

Block Number

Block Size 0x80000

Bank Space 0x400

Actions

Scan

Find Bank Size

Comments

by Vlad forum 4900

FAT was erased

AU6984 ec d5 14 b6 2x1

Layout

AU6984 528

Mix

Input

Order 0/1

Join by Byte

Parts 2

Data false

Block Pair

Block 0x100000

Page 0x2000

Assembler

Block Number

Block Size 0x200000

Bank Space 0x400

Actions

Scan

Find Bank Size

Comments

by Arvika

dump order can be other

AU6984 ec d7 55 b6 1x1

Layout

AU6984 528

Mix

Input

Order 0

Block Pair

Block 0x80000

Page 0x1000

Assembler

Block Number

Block Size 0x100000

Bank Space 0x400

Actions

Scan

Find Bank Size

Comments

KostikN 28.02.2011 100% результат

AU6984 ec d7 55 b6 1x2

Layout

AU6984 528

Mix

Input

Order 0/1

Block Pair

Block 0x80000

Page 0x1000

Join by Page

Parts 2

Page 0x2000

Assembler

Block Number

Block Size 0x200000

Actions

Scan

Find Bank Size

Comments

KostikN 09.02.2012 100% Ñ€ÐµÐ·ÑƒÐ»ÑŒÑ‚Ð°Ñ‚

AU6984 ec d7 55 b6 2x2

Layout

AU6984 528

Mix

Input

Order 0/2/1/3

Join by Byte

Parts 2

Join by Dump

Parts 2

Assembler

Block Number

Block Size 0x100000

Bank Space 0x400

Actions

Scan

Find Bank Size

Comments

Check Dirs

KostikN 26.04.2011 100% результат

AU6984 ec d7 55 b6 2x2 v2

司法鉴定，质量鉴定, 电子数据，声像资料

f0jflash extractor

Layout

AU6984 528

Mix

Input

Order 0/2/1/3

Join by Byte

Parts 2

Data false

Block Pair

Block 0x100000

Page 0x2000

Join by Page

Parts 2

Page 0x4000

Assembler

Block Number

Block Size 0x400000

Bank Space 0x400

Actions

Scan

Find Bank Size

Comments

by Vlad cs 669

perfect recovery

AU6984 ec d7 55 b6 2x4

司法鉴定，质量鉴定, 电子数据，声像资料

f0jflash extractor

Layout

AU6984 528

Mix

Input

Order 0/4/1/5/2/6/3/7

Join by Byte

Parts 2

Block Pair

Block 0x100000

Page 0x2000

Join by Page

Parts 2

Page 0x4000

Join by Dump

Parts 2

Assembler

Block Number

Block Size 0x400000

Bank Space 0x400

Actions

Scan

Find Bank Size

Comments

Check conficts

By Arvika - Einstein case
