IT1167

IT1167 BE-48A   2c 68 04 4a   2x1   j2Lflash extractor   Layout IT1167 1086_1078 v2 Xor 6771_256 Mix Input Order 1/0 Block Pair Block 0x100000 Page 0x1000 Divide Field Block Number Value 0x20 Join by Page Parts 2 Page 0x200000 Cross Block Field Block Number Block 0x200000 Parts 2 Assembler Block Number Block Size 0x200000 Bank Space 0x4000 Image Cut 0xdf200 Mix 2 / 0x200 Banks 0 / 0x000 / 0xfff Actions Scan Comments Serg for forum 5624

j2Lflash extractor

j2Lflash extractor

j2Lflash extractor

j2Lflash extractor

Layout
  IT1167 1086_1078 v2 Xor 6771_256
Mix
  Input
    Order  0
  Divide
    Field  Block Number
    Value  0x10
  Cross Block
    Field  Block Number
    Block  0x100000
    Parts  2
Assembler
  Block Number
    Block Size   0x100000
    Bank Space   0x4000
    Image Cut    0x5f200

    Banks        00 / 0x000 / 0xfff
    Mix          2 / 0x1000
  Actions
    Scan
Comments
  Serg for forum 11343

j2Lflash extractor

j2Lflash extractor

Layout
  IT1167 1086_1078 v2 Xor 6771_256
Mix
  Input
    Order  0
  Block Pair
    Block  0x200000
    Page   0x2000
  Divide
    Field  Block Number
    Value  0x20
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x4000
    Image Cut    0xe7000
    Banks        00 / 0x000 / 0x3ff
  Actions
    Scan
Comments
    By Arvika
    Dir structure corrupted because some blocks missing
    Scan image by other software

IT1167BE-48A   89 88 24 4b   1x2   j2Lflash extractor   Layout IT1167 1086_1078 v2 Xor 6771_256 Mix Input Order 0/1 Block Pair Block 0x200000 Page 0x2000 Divide Field Block Number Value 0x40 Join by Page Parts 2 Page 0x400000 Cross Block Field Block Number Block 0x400000 Parts 2 Assembler Block Number Block Size 0x400000 Bank Space 0x4000 Image Cut 0xc6200 Banks 00 / 0x000 / 0xf27 Mix 2 / 0x4000 Actions Scan Comments Serg for forum 5809

j2Lflash extractor

Layout
  IT1167 1086_1078 Xor 6771_512_BN
Mix
  Input
    Order  1/0
  Block Pair
    Block  0x200000
    Page   0x2000
  Join by Page
    Parts  2
    Page   0x400000
  Divide
    Field  Block Number
    Value  0x40
  Cross Block
    Field  Block Number
    Block  0x400000
    Parts  2
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x1000
    Image Cut    0xc6200
    Banks        00 / 0x000 / 0xfff
    Mix          2/0x200
  Actions
    Scan
Comments
  by Vlad forum 5405
  FAT was corrupted
  good recovery

IT1167BE-48A   89 88 24 4b   2x2   j2Lflash extractor   Layout IT1167 1086_1078 v2 Xor 6771_256 Mix Input Order 2/0/3/1 Block Pair Block 0x200000 Page 0x2000 Divide Field Block Number Value 0x80 Cross Dump Field Block Number Parts 4 Step 1 Assembler Block Number Block Size 0x400000 Bank Space 0x4000 Image Cut 0xc4200 Banks 00 / 0x000 / 0x1fff Mix 2/0x200 2/0x8000 Comments Serg for forum 11055 May be need add Image Cut

j2Lflash extractor

Layout
  IT1168 1078_1070
Mix
  Input
    Order  0
  Block Pair
    Block  0x80000
    Page   0x1000
  Divide
    Field  Block Number
    Value  0x8
Assembler
  Block Number
    Block Size   0x100000
    Bank Space   0x4000
    Image Cut    0x5f200
    Banks        00 / 0x000 / 0xfff
  Actions
    Scan
Comments
  Serg for forum 5828

j2Lflash extractor

Layout
  IT1168 1078_1070 Xor 6771_192
Mix
  Input
    Order  0
  Block Pair
    Block  0x180000
    Page   0x2000
  Divide
    Field  Block Number
    Value  0x18
Assembler
  Block Number
    Block Size   0x300000
    Bank Space   0x4000
    Image Cut    0x45f200
    Banks        00 / 0x000 / 0x56d
  Actions
    Scan
Comments
  Serg for forum 8567

j2Lflash extractor

Layout
  IT1168 1078_1070 Xor 6771_192
Mix
  Input
    Order  0
  Block Pair
    Block  0x180000
    Page   0x2000
  Divide
    Field  Block Number
    Value  0x18
Assembler
  Block Number
    Block Size   0x300000
    Bank Space   0x1000
    Image Cut    0x45f200
    Banks        00 / 0x000 / 0x578
  Actions
    Scan
Comments
  Serg for forum 10076

j2Lflash extractor

Layout
  IT1167 1086_1078
Mix
  Input
    Order  0
  Block Pair
    Block  0x200000
    Page   0x2000
  Divide
    Field  Block Number
    Value  0x20
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x400
    Image Cut    0x5f200
    Scan Back    true
  Actions
    Scan
    Find Bank Size
Comments
  by Vlad forum 5348
  FAT was corrupted

j2Lflash extractor

Layout
  IT1167 1086_1078 v2 Xor 6771_256
Mix
  Input
    Order  0
  Block Pair
    Block  0x100000
    Page   0x2000
  Divide
    Field  Block Number
    Value  0x10
Assembler
  Block Number
    Block Size   0x200000
    Bank Space   0x4000
    Image Cut    0x5f200
    Banks        00 / 0x000 / 0x7ff
  Actions
    Scan
Comments
  Serg for forum 6858
  Some folders was erased with FF

j2Lflash extractor

Layout
  IT1167 1086_1078 v2 Xor 6771_256
Mix
  Input
    Order  0/1/2/3
  Block Pair
    Block  0x200000
    Page   0x2000
  Divide
    Field  Block Number
    Value  0x80
  Join by Page
    Parts  4
    Page   0x400000
  Cross Block
    Field  Block Number
    Block  0x400000
    Parts  4
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x4000
    Image Cut    0xc4200
    Banks        00 / 0x000 / 0x1fff
    Mix          4 / 0x4000
  Actions
    Scan
Comments
  Serg for forum 6688

j2Lflash extractor

Layout
  IT1167 1078_7 Xor 6771_64
Mix
  Input
    Order  0
  Block Pair
    Block  0x200000
    Page   0x2000
  Divide
    Field  Block Number
    Value  0x2
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x400
    Image Cut    0xef200
  Actions
    Scan
    Find Bank Size
Comments
  Serg for forum 8658

j2Lflash extractor

Layout
  UT165 1078 Xor 6771 64
Mix
  Input
    Order  0/1
  Block Pair
    Block  0x200000
    Page   0x2000
  Join by Dump
    Parts  2
  Divide
    Field  Block Number
    Value  0x2
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x400
    Image Cut    0xee000
    Banks        00..03 / 0x000 / 0x3c3
  Actions
    Scan
Comments
  by Karol
  perfect recovery after fix one conflict

Layout
  UT165 1070 Xor 6771 64
Mix
  Input
    Order  0
  Block Pair
    Block  0x180000
    Page   0x2000
  Divide
    Field  Block Number
    Value  2
Assembler
  Block Number
    Block Size   0x300000
    Bank Space   0x400
    Image Cut    0x12000
  Actions
    Scan
    Find Bank Size
Comments
  By aj2008

Layout
  UT165 1070 Xor 6771 64
Mix
  Input
    Order  0
  Block Pair
    Block  0x180000
    Page   0x2000
  Divide
    Field  Block Number
    Value  0x2
Assembler
  Block Number
    Block Size   0x300000
    Bank Space   0x400
  Actions
    Scan
    Find Bank Size
Comments
  by Arvika
  MBR corrupted, save image and scan

j2Lflash extractor

Layout
  UT165 1078 Xor 6771 64
Mix
  Input
    Order  0
Assembler
  Block Number
    Block Size   0x200000
    Bank Space   0x4000
    Image Cut    0x77000

    Banks        00 / 0x000 / 0x7ff

    Mix          2/0x2000
  Actions
    Scan
Comments
  Serg for forum 7309

j2Lflash extractor

Layout
  UT165 1078 Xor 6771 64
Mix
  Input
    Order  0
  Block Pair
    Block  0x100000
    Page   0x1000
  Divide
    Field  Block Number
    Value  0x2
Assembler
  Block Number
    Block Size   0x200000
    Bank Space   0x400
    Image Cut    0x71200
  Actions
    Scan
    Find Bank Size
Comments
  Serg for forum 6655

IT1167E 48B   98 d5 94 32   1x1   j2Lflash extractor   Layout UT165 1070 Xor 6771 64 Mix Input Order 0 Cross Block Field Block Number Block 0x100000 Parts 2 Divide Field Block Number Value 2 Assembler Block Number Block Size 0x100000 Bank Space 0x800 Image Cut 0x7b7200 Mix 2/0x2000 Actions Scan Find Bank Size Comments by Vlad forum 4704 FAT was erased change FAT16 to FAT32

j2Lflash extractor

Layout
  IT1167 1078_7 Xor 6771_64
Mix
  Input
    Order  0
  Block Pair
    Block  0x200000
    Page   0x2000
  Divide
    Field  Block Number
    Value  0x2
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x4000
    Image Cut    0xf7000
    Banks        00 / 0x000 / 0x7ff
  Actions
    Scan
Comments
  by Arvika

j2Lflash extractor

Layout
  IT1167 1086_1078 v2 Xor 6771_256
Mix
  Input
    Order  1/0
  Block Pair
    Block  0x200000
    Page   0x2000
  Divide
    Field  Block Number
    Value  0x40
  Join by Page
    Parts  2
    Page   0x400000
  Cross Block
    Field  Block Number
    Block  0x400000
    Parts  2
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x1000
    Image Cut    0xc6200
    Banks        00 / 0x000 / 0xfff
    Mix          2/0x200
  Actions
    Scan
Comments
  by Vlad forum 5007
  some conflicts
  data has got logical damages

Layout
  IT1167 1086_1078
Mix
  Input
    Order  0
  Block Pair
    Block  0x200000
    Page   0x2000
  Divide
    Field  Block Number
    Value  32
Assembler
  Block Number
    Block Size    0x400000
    Bank Space    0x40000
    Image Cut  0xd7200
    Banks         00 / 0x000 / 0x7ff
  Actions
    Scan
Comments
  Serg for forum 4142
  Many bit errors
  But recovery is good

Layout
  IT1168 1078_1070 Xor 6771_192
Mix
  Input
    Order  0/1
  Block Pair
    Block  0x180000
    Page   0x2000
  Join by Page
    Parts  2
    Page   0x300000
  Divide
    Field  Block Number
    Value  48
  Cross Block
    Field  Block Number
    Block  0x300000
    Parts  2
Assembler
  Block Number
    Block Size    0x300000
    Bank Space    0x4000
    Image Cut     0x45f200

    Banks         00 / 0x000 / 0x57b
    Mix           2 / 0x4000
  Actions
    Scan
Comments
  Serg for forum 4414

Layout
  UT165 1070 Xor 6771 64
Mix
Assembler
  Block Number
    Block Size    0x180000
    Bank Space    0x400
    Image Cut  0x48f000
  Actions
    Scan
    Find Bank Size
Comments
  Serg for forum 3866
  100% recovery

Layout
  UT165 1070 Xor 6771_64 JBB
Mix
  Input
    Order  1/0
  Join by Byte
    Parts  2
    Data   false
Assembler
  Block Number
    Block Size    0x300000
    Bank Space    0x800
    Image Cut  0x31f000

    Banks         00 / 0x000 / 0x71d
                  01 / 0x000 / 0x2a7
  Actions
    Scan
Comments
  Serg for forum 2949
  100% recovery
  Nut sure in Bank Space

Layout
  UT165 1078 Xor 6771 64
Mix
  Block Pair
    Block  0x200000
    Page   0x2000
  Divide
    Field  Block Number
    Value  2
Assembler
  Block Number
    Block Size    0x400000
    Bank Space    0x100000
    Image Cut  0x71200
  Actions
    Scan
    Find Bank Size
Comments
  Bank Space unknown

Layout
  UT165 1070 Xor 6771 64
Mix
Assembler
  Block Number
    Block Size    0x100000
    Bank Space    0x400
    Image Cut  0x7b7200
  Actions
    Scan
    Find Bank Size
Comments
  Serg for forum 4191
  100% recovery
  Change FAT16 to FAT32 in MBR

j2Lflash extractor

Layout
  IT1167 1086_1078 v2 Xor 6771_256
Mix
  Input
    Order  2/0/3/1
  Block Pair
    Block  0x200000
    Page   0x2000
  Divide
    Field  Block Number
    Value  0x80
  Join by Page
    Parts  4
    Page   0x400000
  Cross Block
    Field  Block Number
    Block  0x400000
    Parts  4
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x4000
    Image Cut    0xc4200

    Banks        00 / 0x000 / 0x1fff

    Mix          2/0x200
                 2/0x8000
  Actions
    Scan
Comments
  Serg for forum 6721

ITE1167BFN-46A   45 de 94 82   2x1   j2Lflash extractor   Layout IT1167 1086_1078 Xor 6771_512_BN Mix Input Order 1/0 Block Pair Block 0x200000 Page 0x2000 Divide Field Block Number Value 0x40 Join by Page Parts 2 Page 0x400000 Cross Block Field Block Number Block 0x400000 Parts 2 Assembler Block Number Block Size 0x400000 Bank Space 0x4000 Image Cut 0xc6200 Banks 00 / 0x000 / 0xfff Mix 2 / 0x200 Actions Scan Comments Serg for forum 5680

Layout
  IT1167 1086_1078 v2 Xor 6771_256
Mix
  Input
    Order  0
  Block Pair
    Block  0x200000
    Page   0x2000
  Divide
    Field  Block Number
    Value  0x20
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x4000
    Image Cut    0xdf200
    Banks        00 / 0x000 / 0x7ff
  Actions
    Scan
Comments
  Serg for forum 6981

j2Lflash extractor

Layout
  IT1167 1086_1078 Xor 6771_512_BN
Mix
  Input
    Order  1/0
  Block Pair
    Block  0x100000
    Page   0x1000
  Join by Page
    Parts  2
    Page   0x200000
  Divide
    Field  Block Number
    Value  0x20
  Cross Block
    Field  Block Number
    Block  0x200000
    Parts  2
Assembler
  Block Number
    Block Size   0x200000
    Bank Space   0x1000
    Image Cut    0xd7200
    Mix          2/0x200
  Actions
    Scan
    Find Bank Size
Comments
  KostikN 02.07.2012 Good result
