IS902
| IS802B 2c 68 04 46 4x1 |
Layout
IS802B Back 27
Mix
Input
Order 3/1/2/0
Join by Byte
Parts 4
Data true
Block Pair
Block 0x400000
Page 0x4000
Assembler
Block Number
Block Size 0x800000
Bank Space 0x4000
Banks 00 / 0x000 / 0x7ff
Actions
Scan
Comments
Serg for 4772
Unknown file system
Cant test model good
| IS802B 89 68 04 46 4x4 |
Layout
IS802B Back 27
Mix
Input
Order 12/4/8/0/13/5/9/1/14/6/10/2/15/7/11/3
Join by Byte
Parts 4
Data true
Join by Page
Parts 4
Page 0x4000
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x1000
Banks 00 / 0x000 / 0xfff
Actions
Scan
Comments
Serg for forum 3707
Nothing recovered
Too much blocks erased
And look like controller had dead cache memory
Data was writed with additional changed bits
| IS802B ec d7 55 b6 4x2 |
Layout
IS802B Back 16
Mix
Input
Order 6/2/4/0/7/3/5/1
Join by Byte
Parts 4
Data true
Join by Page
Parts 2
Page 0x4000
Assembler
Block Number
Block Size 0x400000
Bank Space 0x4000
Banks 00 / 0x000 / 0x1fff
Actions
Scan
Comments
Serg for forum 4772
| IS902 QK5R0-000 2c 88 04 4b 2x1 |
Layout
IS902 1072 Xor 8ec1
Mix
Input
Order 0/1
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 2
Page 0x4000
Assembler
Block Number
Block Size 0x800000
Bank Space 0x4000
Banks 00 / 0x000 / 0x7ff
Actions
Scan
Comments
Serg for forum 5119
| IS902 QK6MA-000 2c 88 04 4b 2x1 |
Layout
IS902 1072 Xor c113_256
Mix
Input
Order 0/1
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 2
Page 0x4000
Assembler
Block Number
Block Size 0x800000
Bank Space 0x4000
Banks 00 / 0x000 / 0x7ff
Actions
Scan
Comments
Serg for forum 5826
|
|
| IS902 2c 38 00 26 2x1 |
Layout
IS902 1072
Mix
Input
Order 0/1
Block Pair
Block 0x80000
Page 0x1000
Join by Page
Parts 2
Page 0x2000
Assembler
Block Number
Block Size 0x200000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3ff
Actions
Scan
Comments
Serg for forum 10004
| IS902 2c 68 01 a6 2x4 |
Layout
IS902 1072 Xor c113_128
Mix
Input
Order 0/4/1/5/2/6/3/7
Block Pair
Block 0x80000
Page 0x1000
Join by Page
Parts 8
Page 0x2000
Assembler
Block Number
Block Size 0x800000
Bank Space 0x4000
Banks 00 / 0x000 / 0xfff
Actions
Scan
Comments
Serg for forum 7685
| IS902 2c 68 04 4a 2x1 |
Layout
IS902 1072 Xor 4446
Mix
Input
Order 0/1
Block Pair
Block 0x100000
Page 0x1000
Join by Page
Parts 2
Page 0x2000
Assembler
Block Number
Block Size 0x400000
Bank Space 0x4000
Banks 00 / 0x000 / 0x7ff
Actions
Scan
Comments
Serg for forum 6115
|
|
|
| ||||
|
|
| |||
|
|
| IS902 2c 88 04 4b 2x1 |
Layout
IS902 1072 Xor 4446
Mix
Input
Order 0/1
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 2
Page 0x4000
Assembler
Block Number
Block Size 0x800000
Bank Space 0x40000
Banks 00 / 0x000 / 0x7ff
Actions
Scan
Comments
Serg for forum 4147
Good recovery
May be different banks
| IS902 2c 88 04 4b 2x2 |
Layout
IS902 1072 Xor 4446
Mix
Input
Order 0/2/1/3
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 4
Page 0x4000
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x7ff
Actions
Scan
Comments
Serg for forum 6432
| IS902 2c 88 04 4b 4x1 |
Layout
IS902 1072 Xor 8ec1
Mix
Input
Order 0/2/1/3
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 4
Page 0x4000
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x800
Banks 00 / 0x000 / 0x7ff
Actions
Scan
Comments
by Karol
perfect recovery after solving conflicts
|
|
| IS902 89 68 04 46 2x4 |
Layout
IS902 1072
Mix
Input
Order 0/4/1/5/2/6/3/7
Block Pair
Block 0x80000
Page 0x1000
Join by Page
Parts 8
Page 0x2000
Assembler
Block Number
Block Size 0x800000
Bank Space 0x4000
Banks 00 / 0x000 / 0xfff
Actions
Scan
Comments
Serg for forum 5662
| IS902 89 88 24 4b 2x1 |
Layout
IS902 1072 Xor 8f01
Mix
Input
Order 0/1
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 2
Page 0x4000
Assembler
Block Number
Block Size 0x800000
Bank Space 0x4000
Banks 00 / 0x000 / 0x7ff
Actions
Scan
Comments
Serg for forum 4710
| IS902 89 88 24 4b 2x1 v3 |
Layout
IS902 1072 Xor 8ec1
Mix
Input
Order 0/1
Block Pair
Block 0x200000
Page 0x2000
Cross Dump
Field Block Number
Parts 2
Step 1
Assembler
Block Number
Block Size 0x400000
Bank Space 0x4000
Banks 00 / 0x000 / 0xfff
Mix 2/0x4000
Actions
Scan
Comments
Serg for forum 8947
| IS902 89 88 24 4b 2x2 |
Layout
IS902 1072 Xor 8f01
Mix
Input
Order 2/0/3/1
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 4
Page 0x4000
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x800
Banks 00 / 0x000 / 0x7ff
Actions
Scan
Comments
by Vlad forum 4964
some conflicts
| IS902 89 88 24 4b 2x2 v2 |
Layout
IS902 1072 Xor 8ec1
Mix
Input
Order 0/2/1/3
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 4
Page 0x4000
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x800
Banks 00 / 0x000 / 0x7ff
Actions
Scan
Comments
by Vlad forum 5216
conflicts for 0x0 block
FAT was erased
| IS902 89 88 24 4b 2x2 v3 |
Layout
IS902 1072 Xor c113_256
Mix
Input
Order 0/2/1/3
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 4
Page 0x400000
Cross Block
Field Block Number
Block 0x400000
Parts 4
Assembler
Block Number
Block Size 0x400000
Bank Space 0x4000
Banks 00 / 0x000 / 0x1fff
Mix 4/0x4000
Actions
Scan
Comments
Serg for forum 6830
| IS902 89 88 24 4b 2x2 v4 |
Layout
IS902 1072 Xor c113_256 v2
Mix
Input
Order 2/0/3/1
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 4
Page 0x4000
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x7ff
Actions
Scan
Comments
Serg for forum 8644
| IS902 89 88 24 4b 2x4 |
Layout
IS902 1072 Xor c113_256
Mix
Input
Order 0/4/1/5/2/6/3/7
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 8
Page 0x400000
Cross Block
Field Block Number
Block 0x400000
Parts 8
Assembler
Block Number
Block Size 0x400000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 8 / 0x4000
Actions
Scan
Comments
Serg for forum 6244
Need make auto conflicts
| IS902 89 88 24 4b 2x4 v2 |
Layout
IS902 1072 Xor 8ec1
Mix
Input
Order 0/4/1/5/2/6/3/7
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 8
Page 0x4000
Assembler
Block Number
Block Size 0x2000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x7ff
Actions
Scan
Comments
Serg for forum 7820
| IS902 ad d7 94 9a 2x1 |
Layout
IS902 1072 Xor 8f01
Mix
Input
Order 1/0
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 2
Page 0x4000
Assembler
Block Number
Block Size 0x800000
Bank Space 0x400
Banks 00 / 0x000 / 0x3ff
Actions
Scan
Comments
by Vlad forum 4917
some conflicts
| IS902 ec de d5 7a 1x4 |
Layout
IS902 1072 Xor c113_128_ff
Mix
Input
Order 0/1/2/3
Block Pair
Block 0x100000
Page 0x2000
Join by Page
Parts 4
Page 0x4000
Assembler
Block Number
Block Size 0x800000
Bank Space 0x4000
Banks 00 / 0x000 / 0xfff
Actions
Scan
Comments
Serg for forum 5605
| IS902 ec de d5 7a 2x1 |
Layout
IS902 1072 Xor c113_128
Mix
Input
Order 0/1
Block Pair
Block 0x100000
Page 0x2000
Join by Page
Parts 2
Page 0x4000
Assembler
Block Number
Block Size 0x400000
Bank Space 0x4000
Banks 00 / 0x000 / 0xfff
Actions
Scan
Comments
Serg for forum 5474
| IS902 ec de d5 7a 2x2 |
Layout
IS902 1072 Xor c113_128
Mix
Input
Order 0/2/1/3
Block Pair
Block 0x100000
Page 0x2000
Join by Page
Parts 4
Page 0x4000
Assembler
Block Number
Block Size 0x800000
Bank Space 0x4000
Banks 00 / 0x000 / 0xfff
Actions
Scan
Comments
Serg for forum 5541
